Specifications

– Input sensitivity = 1.7mV for 200mV output

– Input loading = 47KΩ in parallel with 100pF

– Maximum input level = 60mV at 1KHz

– Gain = 41.4dB at 1KHz

– Output impedance = 200Ω

– Recommended minimum output load resistance = 5KΩ

– Frequency response (50KΩ output load) = 15Hz (-3dB) to 100KHz (-0.2dB)

– RIAA accuracy (50KΩ output load) = better than +/-0.2dB 100Hz to 100KHz

– Power requirements = 24V AC at 80mA maximum.
