TECHNICAL SPECIFICATIONS
Input Sensitivity
1.7 mV for 200 mV Output

Input Loading
47 kΩ in parallel with 100 pF

Maximum Input Level
60 mV at 1 kHz

Gain
41.4 dB at 1 kHz

Output Impedance
200 Ω

Recommended Minimum Output Load Resistance
5 kΩ

Frequency response (50KΩ output load)
15 Hz (-3 dB) to 100 kHz (-0.2 dB)

RIAA Accuracy (50 kΩ Output Load)
Better than ±0.2 dB 100 Hz to 100 kHz

Power Requirements
24 V AC at 80 mA maximum
