Specifications

DIMENSIONS (W × H × D)
430 x 73 x 347 mm
17” x 2 7/8” x 13 5/8”

FRONT PANEL HEIGHT
60 mm / 2 3/8”

POWER REQUIREMENTS
120V, 60Hz

POWER CONSUMPTION
150W

STANDBY POWER CONSUMPTION
<0.5W

NET WEIGHT
6.8kg (15lbs.)

BTU RATING (4Ω, 1/8th power)
450 BTU/h

POWER OUTPUT
50W/Ch (8Ω)
62W/Ch (4Ω)

TOTAL HARMONIC DISTORTION (THD)
<0.03%

FREQUENCY RESPONSE
Line Level Inputs: 10Hz – 100kHz, -0.5dB， +0.05dB
Phono Input: 20Hz – 20kHz, -0.5dB, +0.3dB

S/N RATIO (IHF “A” Weighted)
Line Level Inputs: 90dB
Phono Input: 85dB
